Product Specification:
About the Adapter
Adapter Thickness: 1"
Adapter Bolt Pattern Fit to Hub: 4x4.25"(4x108mm)
Adapter Bolt Pattern Fit to Wheel: 4x4.25"(4x108mm)
Adapter Center Bore: 71mm
Adapter Hub Ring: No
Adapter Overall Diameter: 150mm
Adapter Stud Thread Pitch: M12x1.5
Adapter Stud Grade: 10.9
Adapter Color: Chrome or Black Depending on Current Batch
Adapter Material: Cold Forged 6061 T6 Grade Aluminum
Requirements of the Vehicle Specification
Required Vehicle Hub Bolt Pattern: 4x4.25"(4x108mm)
Required Vehicle Hub Center Bore: 71mm or smaller
Required Vehicle Hub Stud Thread: M12x1.5
Min Required Vehicle Fender Gap: 1"
Max Vehicle Hub Stud Length: 1"
*If your stud is longer than 1" you will need to trim it to use the adapter.
Requirements of the Wheel Specification
Required Vehicle Wheel Bolt Pattern: 4x4.25"(4x108mm)
Required Vehicle Wheel Center Bore: 71mm or smaller
Required Vehicle Wheel Lug Thread: M12x1.5
Required Vehicle Wheel Lug Nuts Hex: Based on your Wheel
